Specifikacija
| Dalies numeris | 507562FIS |
|---|---|
| EAN | 4048962087451 |
| Gamintojas | Fischer |
| Vienetas | Box |
| Bracing | Split anchor |
| Anchor model | External thread |
| Fastening provision | Nut |
| Screwing system | Outside hexagon |
| Material anchor | Stainless steel |
| Material quality anchor | A4 (steel) |
| Surface protection anchor | None |
| With collar | No |
| Sriegio tipas | Metrinis |
| Sriegio diametras | M10 |
| Sriegio ilgis | 136 mm |
| Ilgis | 175 mm |
| Fastening by expander tool | No |
| Drill hole diameter | 10 mm |
| Min. drill hole depth | 168 mm |
| Push-through installation | Yes |
| Pre-positioned installation | Yes |
| Spaced installation | No |
| Effective anchorage depth | 50 mm |
| Max. clamping thickness | 100 mm |
| Rakto dydis | 17.0 mm |
| Number of nuts | 1 |
| Number of washers | 1 |
| Kiekis pardavimo vienete | 20 pcs |
| Manufacturer Product ID | 507562 |
