Specifikacija
| Dalies numeris | 3470PVJ080P62 |
|---|---|
| EAN | 4031582328820 |
| Gamintojas | Tente |
| Vienetas | Vnt. |
| Wheel diameter | 80 mm |
| Wheel width | 35 mm |
| Wheels type | Swivel wheel |
| With break | No |
| Fitting type | Plate fitting |
| Dynamic load capacity | 70 kg |
| Static load capacity | 140 kg |
| Total height | 108 mm |
| Body material | Plienas |
| Wheel material | Rubber |
| Wheel hardness | A85 |
| Bearing type | Roller |
| Plate length | 105 mm |
| Plate width | 85 mm |
| Mounting holes distance – length side | 77-80 mm |
| Mounting holes distance | 60-60 mm |
| Center hole diameter | 9 mm |
| Offset | 44.5 mm |
| Swivel diameter | 169 mm |
| Swivel radius | 85 mm |
| Min working temperature | -20 °C |
| Max working temperature | 60 °C |
| Svoris | 0.757 kg |
| EN Standard | 12532 |
