Specifikacija
| Dalies numeris | 553490240074 |
|---|---|
| EAN | 8012823092041 |
| Gamintojas | Finder |
| Vienetas | Vnt. |
| Type of electric connection | Plug-in connection |
| Complete with socket | No |
| With detachable clamps | No |
| With LED indication | Yes |
| Rated control supply voltage Us at DC | 24.0-24.0 V |
| Voltage type for actuating | DC |
| Drive, polarization | Polarity free |
| Drive, switching attitude | Mono stable |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 0 |
| Number of contacts as change-over contact | 4 |
| Type of switch contact | Single contact |
| With forced-guided contacts | No |
| Material contact | Silver nickel (AgNi) |
| Voltage type (operating voltage) | DC |
| Operating voltage DC | 19.2-26.4 V |
| Nominal current | 7 A |
| Max. starting current | 15 A |
| Relay technology category according to IEC 61810-7 | RT I |
| Plotis | 20.7 mm |
| Aukštis | 37.2 mm |
| Gylis | 27.7 mm |
| Manufacturer Product ID | 55.34.9.024.0074 |
