Specifikacija
| Dalies numeris | 466190120040 |
|---|---|
| EAN | 8012823301648 |
| Gamintojas | Finder |
| Vienetas | Vnt. |
| Type of electric connection | Plug-in connection |
| Complete with socket | No |
| With detachable clamps | No |
| With LED indication | No |
| Sudaro | – Relays – Without accessories |
| Rated control supply voltage Us at DC | 12.0-12.0 V |
| Voltage type for actuating | DC |
| Drive, polarization | Polarity free |
| Drive, switching attitude | Mono stable |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 0 |
| Number of contacts as change-over contact | 1 |
| Type of switch contact | Single contact |
| With forced-guided contacts | No |
| Material contact | Silver nickel (AgNi) |
| Voltage type (operating voltage) | DC |
| Operating voltage DC | 8.8-13.2 V |
| Nominal current | 16 A |
| Max. starting current | 25 A |
| Relay technology category according to IEC 61810-7 | RT II |
| Plotis | 12.4 mm |
| Aukštis | 32.8 mm |
| Gylis | 29 mm |
| Manufacturer Product ID | 46.61.9.012.0040 |
