Specifikacija
| Dalies numeris | 830202400000 |
|---|---|
| EAN | 8012823358420 |
| Gamintojas | Finder |
| Vienetas | Vnt. |
| Voltage type for actuating | AC, DC |
| Manufacturer Product ID | 83.02.0.240.0000 |
| Voltage type (operating voltage) | AC, DC |
| Clock function, starting with pause, variable | No |
| Clock function, starting with pulse, variable | No |
| Complete with socket | No |
| Gylis | 100.3 mm |
| Function delay on de-energization | Yes |
| Function delay-on energization | Yes |
| Function flashing, starting with pulse, fixed time | Yes |
| Function floating contact on de-energization | No |
| Function floating contact on energization | Yes |
| Function pulse shaping | Yes |
| Function star-delta | No |
| Aukštis | 86.2 mm |
| Insulation class | 20 |
| Material contact | Silver nickel (AgNi) |
| Max. starting current | 30 A |
| Nominal current | 12 A |
| Number of outputs, delayed, change-over contact | 2 |
| Number of outputs, delayed, normally open contact | 0 |
| Number of outputs, undelayed, change-over contact | 1 |
| Number of outputs, undelayed, normally open contact | 0 |
| Operating voltage AC 50 Hz | 16.8-265.0 V |
| Operating voltage AC 60 Hz | 16.8-265.0 V |
| Operating voltage DC | 16.8-265.0 V |
| Outputs, reversible delayed/undelayed | Yes |
| Pluggable on auxiliary contact block | No |
| Rated control supply voltage Us at DC | 24.0-240.0 V |
| Rated control supply voltage Us at AC 60HZ | 24.0-240.0 V |
| Rated control supply voltage Us at AC 50HZ | 24.0-240.0 V |
| Remote operation possible | No |
| Suitable for DIN rail (top hat rail) mounting | Yes |
| Suitable for front mounting | No |
| Suitable for remote control | No |
| Time range | 0.050-864000.0 s |
| Type of electric connection | Screw connection |
| Plotis | 22.5 mm |
| With semiconductor output | No |
